GRUVLOCK® FLANGE DOM
The Gruvlok® Fig. 7012 Flange allows direct connection of Class 125 or Class 150 flanged components to a grooved piping system. The two interlocking halves of the 2" thru 12" sizes of the Gruvlok Flange are hinged for ease of handling, and are drawn together by a latch bolt, which eases assembly on the pipe. Precision machined bolt holes, key and mating surfaces assure concentricity and flatness to provide exact fit-up with flanged, lug, and wafer styles of pipe system equipment. A specially designed gasket provides a leak-tight seal on both the pipe and the mating flange face.
The 14" thru 24" sizes of the Gruvlok Fig. 7012 Flange are cast in four segments. A sleek profile gasket design allows quick and easy assembly of the Gruvlok Flange onto the pipe.
All Gruvlok Fig. 7012 Flanges have designed-in anti-rotation tines which bite into and grip the sides of the pipe grooves to provide a secure, rigid connection.
| Item Number | DGFLG |
|---|---|
| Brand | ASC Engineered Solutions |
| Item Numbers | Description | Price Group | UM |
|---|---|---|---|
| 3DGFLGG | 3 GRV FLANGE DOM GALV | SR361.5 | EA |
| 4DGFLGG | 4 GRV FLANGE DOM GALV | SR361.5 | EA |
| 6DGFLGG | 6 GRV FLANGE DOM GALV | SR361.5 | EA |
| 8DGFLGG | 8 GRV FLANGE DOM GALV | SR361.5 | EA |
| 10DGFLG | 10 GRV FLANGE DOM | SR362.2 | EA |
| 12DGFLG | 12 GRV FLANGE DOM | SR362.2 | EA |
| 2DGFLG | 2 GRV FLANGE DOM | SR361.5 | EA |
| 212DGFLG | 2 1/2 GRV FLANGE DOM | SR361.5 | EA |
| 3DGFLG | 3 GRV FLANGE DOM | SR361.5 | EA |
| 4DGFLG | 4 GRV FLANGE DOM | SR361.5 | EA |
| 5DGFLG | 5 GRV FLANGE DOM | SR361.5 | EA |
| 6DGFLG | 6 GRV FLANGE DOM | SR361.5 | EA |
| 8DGFLG | 8 GRV FLANGE DOM | SR361.5 | EA |
| 10DGFLGG | 10 GRV FLANGE DOM GALV | SR362.2 | EA |
| 2DGFLGG | 2 GRV FLANGE DOM GALV | SR361.5 | EA |
| 212DGFLGG | 2 1/2 GRV FLANGE DOM GALV | SR361.5 | EA |
| 5DGFLGG | 5 GRV FLANGE DOM GALV | SR361.5 | EA |
| 12DGFLGG | 12 GRV FLANGE DOM GALV | SR362.2 | EA |
